Supply Boats

SB296

Length: 190 ft 0 in (57.9 m)

Draft Max: 13 ft 6 in (4.11 m)
Gross: Draft Min: 8 ft 0 in (2.44 m)
1,226 GT
Beam: 54 ft 0 in (16.5 m)
Net: 367 NT

SB300

Offshore Supply Vessel
YEAR 1977 – Converted to OSV 2000
REGISTRY U.S.
GT 411
NT 279
DIMENSINS 214′ x 40′ x 14′
DRAFT 5′ 9 5/8″
11′ 8″
SPEED LIGHT12.5 knots
SPEED LOAD 11 knots
CLEAR DECK SPACE 144′ x 31′
DECK AREA DEADWEIGHT 4,464 Sq. Ft.
LL DRAFT 1,150 LT
HORSEPOWER 3000HP
MAIN ENGINES (2) EMD 12-645 C
BOW TRUSTER 230 HP @ 1800 RPM
(4 1/4″ bore, 5″ Stroke, Detroit
Diesel 8 V-71 N) 97,497 Gallons
FUEL OIL  141,910 Gallons
POTABLE WATER 14,496 Gallons
LIQUID MUD 1,880 Bbls – 4 Tanks
DRY BULK 5,800 Cu. Ft. @ 80 PSI
TOTAL ACCOMODATION 15
CREW 6
PASSENGERS

9

RADAR (1) JRC model 3860 10cm
(1) Furuno model FP8051 10cm

NAVTEX Furuno model NX500

GPS JRC model J/NAV-500

DEPTH FINDER International Offshore model 3000

LOUDHAILER Ray Jefferson model 315

VHF (2) JRC model JHS-32A

GMDSS / SIDEBAND EQUIPMENT JRC model JSS-800
fitted with a necode model 322ARX

INMARSAT-C model JUE-75C

AUTOPILOT (1) Robertson model AP9
(1) Sperry

TELEPHONE Motorola cell phone
Westinghouse series 1000 satelitte phone



SB299

DESCRIPTION

Length Overall . . . . 240’
Beam Molded . . . . 54’
Depth to Main Deck .. . 20’
Cargo Deck. . .170 X 45’ = 7650 SQ. FT.
Cargo Deck Capacity .. . . .1200 Long Tons
Design Cargo Deck Loading. . . 1000 lbs/sq ft.
Maximum Speed. . . . . . . . 12.5 Knots
Draft: Light 11’
Maximum .. . 16’

CAPACITIES

Total Fuel Oil . 221,000 Gallons
Fresh Water for Ship . . . 38,950
Fresh Water Ballast . 284,000
Sea Water Ballast.. . . . . . 27,350
Total Misc. Oil . . 5,258
Drilling Fluid (10 tanks @ 463 & 1 @ 300) . . 4,930 BBLS
Bulk Mud (5 tanks @ 1600 cu. ft.) . . .8,000 Cubic Feet
Sewage Holding . 2,300 Gallons
Bilge Slop . . 1,690 Gallons
Dirty Oil.. . 1,690 Gallons

MACHINERY

Main Engines . . . . . (4) Caterpillar3512@1360 KW each
Z-Drive Units. . . . (2)Kamewa Aquamaster 2001
Emergency Generator .. ..(1) Caterpillar 95 KW
Bow Thruster (Tunnel) . . . . . (2) Kamewa Aquamaster TT1650K/BMS-CP 918 HP
Dynamic Positioning System . . . . . Alstom

SB298-2

DESCRIPTION

Length Overall . . . 240’
Beam Molded .. . . . 54’
Depth to Main Deck . . . . 20’
Cargo Deck.. . .170 X 45’ = 7650 SQ. FT.
Cargo Deck Capacity . . .1200 Long Tons
Design Cargo Deck Loading.. . 1000 lbs/sq ft.
Maximum Speed. . 12.5 Knots

Draft:

Light . . . . 11’
Maximum . . . 16’

CAPACITIES

Total Fuel Oil . . . 221,000 Gallons
Fresh Water for Ship . . . 38,950
Fresh Water Ballast . . . . 284,000
Sea Water Ballast. .. . . 27,350
Total Misc. Oil . . 5,258
Drilling Fluid (10 tanks @ 463 & 1 @ 300) . 4,930 BBLS
Bulk Mud (5 tanks @ 1600 cu. ft.) .8,000 Cubic Feet
Sewage Holding . . 2,300 Gallons
Bilge Slop . . . . 1,690 Gallons
Dirty Oil. . . . . 1,690 Gallons

MACHINERY

Main Engines . . . . (4) Caterpillar3512@1360 KW each
Z-Drive Units. . . . (2)Kamewa Aquamaster 2001
Emergency Generator . ..(1) Caterpillar 95 KW
Bow Thruster (Tunnel) .. . . (2) Kamewa Aquamaster TT1650K/BMS-CP 918 HP
Dynamic Positioning System . . Alstom

SB298

190x54x13.6

Flag: Mexico
Certifications: Oceans-SOLAS
Classifications: Loadline, American Bureau of Shipping, +DPS-1, +A1, +AMS

Main Engines: 2 x Caterpillar 3516B Total Horsepower: 4,000 hp
Propellers: FPP, High-Efficiency, 5-Blade Propeller Diameter: 96 in (2,438mm)
Primary Generators: 3 x Caterpillar 3406B Total Rating: 750 kW
Bow Thruster: 1 x Brunvoll CPP Tunnel Total Rating: 600 hp
Rudder: Independent Steering, Schilling Fishtail Power Generation: 480V/60
Hz/3-Phase

Contact for more information ,please provide file # SB298 with inquiry

SB297

220 x 46 x 13.8/min draft 9′

1,199GT/359NT

(2) EMD 16-645E6 3900hp

Contact for additional information and price.

SB296-2

DESCRIPTION

SISTER VESSEL

Length Overall … 240’
Beam Molded . . . 54’
Depth to Main Deck . . . . . 20’
Cargo Deck . . . . 170 X 45’ = 7650 SQ. FT.
Cargo Deck Capacity . .1200 Long Tons
Design Cargo Deck Loading .. . . 1000 lbs/sq ft.
Maximum Speed . 12.5 Knots

Draft:
Light . . . 11’
Maximum . . 16’



Contact for additional information

SB294

205 x 34 x 14

Deck Space 3,715 sg ft

Speed 30 Kts

SB295

220 x 46 x 13.8/min draft 9′

1,199GT/359NT

(2) EMD 16-645E6 3900hp

Contact for additional information and price.

SB291

231′ x 40′ x 14′

Light Draft 5.6′

Loaded Draft 11.2′

Deck Strength 2.6 t/m

Clear Deck 158 x 28

Clear Deck are 4,457′

Portable Water 10,250

Fuel 113,000

OIl/Lube 1,918 USG

Bulk Tank  (4) 6,000

Walk in cooler 247′
